vmc milling machine 3axis cnc With CE Certified vmc machine price VMC machine CNC GSK system BT40 Machining Center

Description

• Condition : New
• Spindle Taper : BT40
• No. of Spindles : Single
• Type : VERTICAL
• Dimension(L*W*H) : 2300*1950*2450mm
• Weight (T) : 5
• Table Size (mm) : 800X500X500
• CNC Control System : GSK
• Table Travel (X) (mm) : 650
• Table Travel (Y) (mm) : 400
• Table Travel (Z) (mm) : 500
• Positioning Accuracy (mm) : 0.008
• Repeatability (X/Y/Z) (mm) : 0.005
• Range of Spindle Speed(r.p.m) : 8000 – 10000 r.p.m
• Max. Table Load(kg) : 500 kg
• Min. Time of Tool Change(s) : 6
• Tool Magazine Capacity : 16, 10, 12, 24, 32, 40
• Key Selling Points : Automatic
• Warranty : 1 Year
• Place of Origin : SHANDONG
• Brand Name : UnionTech
• Voltage : 220v/380v
• Marketing Type : Other
• Machinery Test Report : Provided
• Video outgoing-inspection : Provided
• Warranty of core components : 1 Year
• Machining Capacity : Light Duty
• Rapid Feed Speed(mm/min) : 1 – 6000 mm/min
• After-sales Service Provided : Engineers available to service machinery overseas
• Working area : 650*400*500mm
• Control system : GSK/SYNTEC/FANUC
• Spindle : 7.5KW Mechnical Spindle
• Machine structure : Cast iron
• X, Y, Z Transmission : Japanese NACHI ball screw
• Guide rails : HIWIN 35 for X, Y, Z axis
• Tool Storage : 16/20/24/30 ATC
• External protection : Fully enclosed external protection
• Name : CNC Milling Machine
